Track Etched Membrane

it4ip develops, manufactures, and sells extremely high precision Track Etched Membranes made of PC, PET, and PI. These membranes can be used in the medical and biotechnology fields, in the development of next-generation batteries such as secondary batteries, in various filtration applications such as food and pharmaceuticals, and in the development of various nanotechnology materials. We can also provide ipCELLCULTURE for cell culture (substrate treatment and Transparent/Translucent for cell culture) and ipBLACK for microorganisms.

it4ip开发、制造和销售由PC、PET和PI制成的高精度轨道蚀刻膜。这些膜可用于医疗和生物技术领域，用于二次电池等下一代电池的开发，用于食品和药品等各种过滤应用，以及各种纳米技术材料的开发。我们还可以提供用于细胞培养的ipCELLCULTURE（基质处理和细胞培养的透明/透亮）和用于微生物的ipBLACK。

it4ip Movie (English)

it4ip Movie (Chinese)

Microbial collection using ipPORE on the membrane surface
在膜表面使用ipPORE收集微生物

ipPORE (0.4 μm) reliably collects B. subtilis on the membrane surface.
ipPORE(0.4 μm)可靠地收集膜表面的枯草芽孢杆菌

Compare the SEM　pictures

Conventional nitrocellulose membranes (0.45 μm) have non-uniform pore size, allowing B. subtilis to penetrate deep into the membrane.
传统的硝化纤维素膜(0.45μm)具有非均匀的孔径，使枯草芽孢杆菌能深入膜内。

Reliable track-etched membrane with high-precision pore size. ipPORE, ipBLACK, ipCELLCULTURE
可靠的履带式蚀刻膜，具有高精度的孔径尺寸

Track-etched membranes are very thin polymer films with pores dispersed over a smooth surface.
Track-etched membranes are available in hydrophilic and hydrophobic types, both of which have high chemical resistance. They can be used for substance separation, flow control, support and screening.
Track-etched membranes are used in various products and developments such as direct observation and rapid quantification of living cells or microorganisms, cell culture, cancer diagnosis, Diffusion Control in biosensors, particle capture testing, and development of next generation batteries.
In addition to the standard ipPORE, we also offer ipBLACK, a true black membrane for epifluorescence microscopy, and ipCELLCULTURE, which allows cell culture on a porous membrane (substrate treatment and transparent/translucent for cell culture).
履带式蚀刻膜是一种非常薄的聚合物薄膜，在光滑的表面上散布着孔隙。
轨迹蚀刻膜有亲水型和疏水型两种，都具有较高的耐化学性。它们可用于物质分离、流量控制、支撑和筛选。
跟踪蚀刻膜被应用于各种产品和开发中，如活细胞或微生物的直接观察和快速定量、细胞培养、癌症诊断、生物传感器中的扩散控制、颗粒捕获测试和下一代电池的开发。
除了标准的ipPORE，我们还提供ipBLACK，一种用于外显荧光显微镜的真正的黑色膜，以及ipCELLCULTURE，它可以在多孔膜上进行细胞培养（经过基质处理，细胞培养用透明/半透明）。

Applications/应用

Optical microscope and scanning electron microscope observation of supplementary materials/光学显微镜和扫描电子显微镜观察补充材料
Filtering nanoparticles in liquids/清洗液体中的纳米颗粒
Particle counting in liquids and gases/液体和气体中的粒子计数
Microbiological inspection by acridine orange staining (epifluorescence microscopy) /吖啶橙染色的微生物检查（外显镜）
Microbiological examination by Proca staining method/用Proca染色法进行微生物检查
Microbiological examination by ATP method using luciferin-luciferase reaction/利用荧光素-荧光素酶反应的ATP法进行微生物检查
Cell analysis/diagnosis/细胞诊断
Cell culture (Chemotaxis)/细胞培养（趋化作用）
Cervical cancer test kit/宫颈癌检测试剂盒
Glucose Sensor(artificial pancreas) /胰岛素传感器
Sensor chip (blood)/传感器芯片(血液)
Ion exchange membranes for batteries/电池用离子交换膜
Nanowires/纳米线
Others/其他

“New Idea" + "ipPORE™ Technology" = "New Product / New Application
“新理念"+"ipPORE™技术"="新产品/新应用"

Inquiry Please select from the following specifications and fill in the form to contact us.

We will provide you with feedback on more appropriate specifications.

Material: (PC, PET, PI)
Format: (Disc size (13, 25, 47, 90, 142, 293mm), A4 size, Roll, Slit reel, Others)
Surface characteristics (hydrophilic, hydrophobic, cell culture treatment)
Pore size (select from 0.01um to 30um)
Application (Please select from the following. (Please select more than one) )

・Blood filter
・Battery and capacitor development
・Cell culture insert self-production, manufacturing and development
・Development of POCT kit
・PAP testing
・Material and capture (from liquid and gas)
・Cell culture
・Sensor development
・Microbial testing
・Other (Please tell us as much as possible.)

Important points in the filter (Please indicate the order of importance from the following. (1)...the most important item

・Ease of processing
・Flow velocity (AFR, WFR)
・Heat resistance
・Pore angle
・Pore size accuracy
・Transparency
・Chemical resistance
・Others (Please tell us as much as possible.)

咨询请选择并填写以下规格，然后联系我们

我们会把更合适的规格反馈给您

材料：(PC、PET、PI)
格式：(光盘尺寸(13、25、47、90、142、293mm)、A4尺寸、卷筒、分切卷、其他)
表面特征（亲水、疏水、细胞培养处理）
孔径(从0.01um到30um选择)
应用(请从以下内容中选择。请选择一个以上)

・血液过滤器
・电池和电容器开发
・细胞培养基插入物的自产、制造和开发。
・开发POCT试剂盒
・PAP测试
・材料和捕获（来自液体和气体）
・细胞培养
・传感器开发
・微生物检测
・其他（请尽可能多地告诉我们

过滤器中的重要点（请从以下几个方面注意重要性的顺序。 (1).最重要的项目。

・易于处理
・流速(AFR, WFR)
・耐热性
・孔隙角
・孔径精度
・透明度
・耐化学性。
・其他（请尽可能多地告诉我们

Contact

AR Brown Co., Ltd Life-Science Department
Tokyo:TEL:81-3-3545-5720　FAX:81-3-3543-8865 　　 Osaka:TEL:81-6-6282-4004　FAX:81-6-6282-4005
Contact Form
